性能特点：
本机床是一种结构简单紧凑，操作灵活可靠，使用维修按方便的剪切机床。该产品广泛应用于造船厂、锅炉厂、电机、电器、汽车维修、五金制造及其他金属薄板加工行业。
Performance characteristics:
This machine tool is a simple and compact structure, flexible and reliable operation, and easy to use and maintain shearing machine tool. This product is widely used in shipyards, boiler factories, motors, electrical appliances, automotive maintenance, hardware manufacturing, and other metal sheet processing industries.
技术参数：Technical Specifications:
|
规格
Model |
可剪切最大板厚
Max cutting
Thickness(mm) |
可剪切最大板宽
Max cutting
Width(mm) |
行程次数
No.of stokes
(min-1) |
剪切角度
Rake angle |
后挡料距离
Adj.distance of
Back gauge(mm) |
主电机功率
Power of main motor (kw) |
外型尺寸
Overrall dimensions(mm) |
|
3×2000 |
3 |
2000 |
40 |
1°30′ |
500 |
3 |
2780×1505×1245 |
|
3×2500 |
3 |
2500 |
35 |
1°30′ |
500 |
5.5 |
3280×1505×1245 |
|
4×1300 |
4 |
1300 |
45 |
1°30′ |
350 |
5.5 |
2080×1505×1245 |
|
4×1500 |
4 |
1500 |
45 |
1°30′ |
350 |
5.5 |
2280×1505×1245 |
|
3×1300 |
3 |
1300 |
56 |
1°30′ |
350 |
3 |
2080×1505×1245 |
|
3×1500 |
3 |
1500 |
56 |
1°30′ |
350 |
3 |
2280×1505×1245 |
|
6×2000 |
6 |
2000 |
30 |
2° |
500 |
7.5 |
3175×1765×1530 |
|
6×2500 |
6 |
2500 |
30 |
2° |
500 |
7.5 |
3675×1765×1530 |
|
6×3200 |
6 |
3200 |
30 |
2° |
650 |
7.5 |
4375×1765×1530 |
|
8×2000 |
8 |
2000 |
25 |
2° |
500 |
11 |
3275×1865×1530 |
|
8×2500 |
8 |
2500 |
22 |
2° |
650 |
11 |
3775×1865×1530 |
|
8×3200 |
8 |
3200 |
20 |
2° |
650 |
11 |
4475×1865×1530 |
|
10×2000 |
10 |
2000 |
15 |
2° |
500 |
15 |
3560×2065×1630 |
|
10×2500 |
10 |
2500 |
13 |
2° |
650 |
15 |
4060×2075×1660 |
|
10×3200 |
10 |
3200 |
8 |
2° |
650 |
15 |
4760×2100×1690 |
|
13×2500 |
13 |
2500 |
10 |
3° |
500 |
15 |
3670×2160×2440 |
|
16×2500 |
16 |
2500 |
8 |
3° |
650 |
22 |
3595×2160×2440 |
|
20×2500 |
20 |
2500 |
6 |
3° |
650 |
30 |
3737×2830×2654 |
