性能特点：
→ 机架、刀架振动消除应力，整机焊接，经久耐用。
→ 先进的集成式液压系统，可靠性好。
→ 采用三点支承滚动导轨，消除支承间隙，保证剪切质量。
→ 刀片间隙手动或电动调整，快速、准确。
→ 上下刀片采用四面刃，增加使用时间，延长刀片的使用寿命。
→ 剪切角可电动调整，最大限度的减小板材变形量。
→ 具有分段定长剪切功能。
→ 自动充液功能。
→ 电动后挡料、数字显示，准确可靠。
→ 剪切端面、剪切速度、剪切厚度优于同规格液压摆式剪板机。
Performance characteristics:
The frame and tool holder vibrate to eliminate stress, and the whole machine is welded for durability.
Advanced integrated hydraulic system with good reliability.
Using three-point support rolling guide rails to eliminate support gaps and ensure shear quality.
Manual or electric adjustment of blade clearance, fast and accurate.
The upper and lower blades adopt four sided blades to increase the usage time and extend the service life of the blades.
The cutting angle can be electrically adjusted to minimize the deformation of the sheet metal to the greatest extent possible.
→ It has the function of segmented fixed length cutting.
→ Automatic liquid filling function.
Electric rear gear shift and digital display, accurate and reliable.
The cutting end face, cutting speed, and cutting thickness are superior to those of hydraulic swing shearing machines of the same specifications.
技术参数：Technical Specifications:
|
规格
Model |
可剪切最大板厚
Max cutting
Thickness(mm) |
可剪切最大板宽
Max cutting
Width(mm) |
行程次数
No.of stokes
(min-1) |
剪切角度
Rake angle |
后挡料距离
Adj.distance of
Back gauge(mm) |
主电机功率
Power of main motor (kw) |
外型尺寸
Overrall dimensions(mm) |
|
12×2500 |
12 |
2500 |
12～25 |
0.5～2° |
20～800 |
15 |
3150×1600×2200 |
|
12×3200 |
12 |
3200 |
12～25 |
0.5～2° |
20～800 |
15 |
3960×1800×2500 |
|
12×4000 |
12 |
4000 |
8～20 |
0.5～2° |
20～800 |
15 |
4750×1900×2555 |
|
12×6000 |
12 |
6000 |
6～20 |
0.5～2° |
20～1000 |
30 |
6760×1980×2568 |
|
16×2500 |
16 |
2500 |
16～20 |
0.5～2.5° |
20～800 |
22 |
3260×1700×2420 |
|
16×3200 |
16 |
3200 |
16～20 |
0.5～2.5° |
20～800 |
22 |
3960×1850×2530 |
|
16×4000 |
16 |
4000 |
8～15 |
0.5～2.5° |
20～800 |
22 |
4850×1900×2600 |
|
16×6000 |
16 |
6000 |
5～20 |
0.5～2.5° |
20～1000 |
37 |
6670×2450×3075 |
所有产品价格均为普机价格，如需特殊配置及数控装置价格另议！
All product prices are for regular machines. If special configurations or CNC devices are required, prices will be negotiated separately!
